SGS - #68, 130° Drill Point, 1/8" Shank Diam, Regular Spiral Circuit Board Drill Bit - Exact Tooling

SGS - #68, 130° Drill Point, 1/8" Shank Diam, Regular Spiral Circuit Board Drill Bit


Item #: 00902684
Brand: SGS
Model #: 07306

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat-resistant and used for high-speed applications on cast iron, non-ferrous materials, plastics and other tough-to-machine materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Product Specifications
Drill Bit Size (mm) 0.79
Drill Bit Size (Wire) #68
Drill Bit Size (Decimal Inch) 0.0310
Drill Point Angle 130
Drill Bit Material Solid Carbide
Drill Bit Finish/Coating Bright
Shank Diameter (Inch) 1/8
Shank Diameter (mm) 3.18
Flute Length (mm) 10.16
Flute Length (Decimal Inch) 0.4000
Overall Length (mm) 38.10
Overall Length (Inch) 1-1/2
Spiral Type Regular Spiral
Web Configuration Tapered
Cutting Direction Right Hand
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0003
Series/List 105
Shank Diameter (Decimal Inch) 0.1250
$ 5.14
