Climax Metal Products - M5 Thread, 18mm Bore Diam, 44mm OD, Shaft Locking Device - 4 Screws, 2,376 Lb Axial Load, 44mm OAW, 0.472" Thrust Ring Width, 99 Ft/Lb Max Torque
Item #: 64649858
Brand: Climax Metal Products
Model #: C733M-18
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M5 |
| Bore Diameter (Decimal Inch) | 0.7090 |
| Bore Diameter (mm) | 18.000 |
| Outside Diameter (Decimal Inch) | 1.7320 |
| Outside Diameter (mm) | 44.0000 |
| Thrust Ring Width (Decimal Inch) | 0.472 |
| Overall Width (Decimal Inch) | 1.7320 |
| Overall Width | 44.0000 |
| Axial Load Lbs (Pounds) | 2376 |
| Maximum Torque (Ft/Lb) | 99 |
| Number of Screws | 4.000 |
| Screw Seating Torque (In/Lb) | 36.000 |
