Climax Metal Products - M6 Thread, 11/16" Bore Diam, 52mm OD, Shaft Locking Device - 3 Screws, 6,423 Lb Axial Load, 2.047" OAW, 1.181" Thrust Ring Width, 184 Ft/Lb Max Torque
Item #: 64650211
Brand: Climax Metal Products
Model #: C600E-068
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M6 |
| Bore Diameter (Inch) | 11/16 |
| Bore Diameter (Decimal Inch) | 0.6875 |
| Outside Diameter (Decimal Inch) | 2.0470 |
| Outside Diameter (mm) | 52.0000 |
| Thrust Ring Width (Decimal Inch) | 1.181 |
| Overall Width (Decimal Inch) | 2.0470 |
| Axial Load Lbs (Pounds) | 6423 |
| Maximum Torque (Ft/Lb) | 184 |
| Number of Screws | 3.000 |
| Screw Seating Torque (In/Lb) | 108.000 |
