Sumitomo - 6 Inserts, 3.1496" Cut Diam, 1" Arbor Diam, 16mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 1-31/32" High, LNMX17 Insert Compatibility, Series PWS
Item #: 65521908
Brand: Sumitomo
Model #: 2200AAJ
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 80.00 |
| Cutting Diameter (Inch) | 3.1496 |
| Cutting Diameter (Decimal Inch) | 3.1496 |
| Arbor Hole Diameter (mm) | 25.40 |
| Arbor Hole Diameter (Inch) | 1 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 0 |
| Overall Height (mm) | 50.00 |
| Overall Height (Inch) | 1.9685 |
| Overall Height (Decimal Inch) | 1.9685 |
| Insert Compatibility | LNMX17 |
| Series | PWS |
| Maximum Depth of Cut (mm) | 16.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.6299 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
