Komet - 80mm Body Diam, Manual Twin Cutter Boring Head - 109mm to 167mm Bore Diam
Item #: 66179383
Brand: Komet
Model #: G0173041
Exact Tooling IR#: 04
Features and Benefits
Boring heads with two cutters (double edges) are used for roughing operations and can remove material twice as fast as single edge cutters .
Integral shank boring heads have the shank built into the head.
| Product Specifications | |
|---|---|
| Type | Twin Cutter Boring Head |
| Actuation Type | Manual |
| Body Diameter (mm) | 80.00 |
| Body Diameter (Decimal Inch) | 3.1500 |
| Mount Type | Integral Shank |
| Shank Type | Modular Connection |
| Modular Connection Size | ABS80 |
| Series | TwinKom G01 |
| Minimum Bore Diameter (Decimal Inch) | 4.2910 |
| Minimum Bore Diameter (mm) | 109.00 |
| Maximum Bore Diameter (mm) | 167.00 |
| Maximum Bore Diameter (Decimal Inch) | 6.5750 |
| Projection (mm) | 175.00 |
| Projection (Decimal Inch) | 6.8898 |
