Cutting Tool Technologies - 4" Cut Diam, 1-1/2" Arbor Hole, 0.67" Max Depth of Cut, 15° Indexable Chamfer & Angle Face Mill - 4 Inserts, CNMG 643 Insert, 4 Flutes, Series SCNM
Item #: 67315945
Brand: Cutting Tool Technologies
Model #: SCNM-720
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 4 |
| Cutting Diameter (Decimal Inch) | 4.0000 |
| Arbor Hole Diameter (Inch) | 1-1/2 |
| Arbor Hole Diameter (Decimal Inch) | 1.5000 |
| Lead Angle | 15 |
| Overall Height (Decimal Inch) | 2.3125 |
| Insert Compatibility | CNMG 643 |
| Maximum Depth of Cut (Decimal Inch) | 0.6700 |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | SCNM |
| Number of Flutes | 4 |
| Rake | Negative |
| Hub Diameter (Decimal Inch) | 1.5000 |
| Maximum Body Diameter (Decimal Inch) | 4.0000 |
| Complete Insert Compatibility | CNMG 643 |
