Iscar - 4 Inserts, 40mm Cut Diam, 16mm Arbor Diam, Indexable Square-Shoulder Face Mill - 0/90° Lead Angle, 40mm High, HTP LNHT 1006 Insert Compatibility, Through Coolant, Series TangPlunge
Item #: 68146547
Brand: Iscar
Model #: 3105160
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 40.00 |
| Arbor Hole Diameter (mm) | 16.00 |
| Lead Angle | 0/90 |
| Overall Height (mm) | 40.00 |
| Insert Compatibility | HTP LNHT 1006 |
| Series | TangPlunge |
| Through Coolant | Yes |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | HTP-R-LN10 |
| Number of Flutes | 4 |
| Hub Diameter (mm) | 38.00 |
| Keyway Width (mm) | 8.40 |
| Maximum Body Diameter (Decimal Inch) | 1.4960 |
| Cutting Edge Length (Decimal Inch) | 0.1180 |
| Counterbore Diameter (Decimal Inch) | 0.5510 |
| Complete Insert Compatibility | HTP LNHT 1006 |
