Associated Spring Raymond - 75mm Rod Diam, 120.2mm Diam, 80mm Max Stroke, Nitrogen Gas Spring Cylinder - 148mm Body Length, 228mm OAL, 23,400 Lb Full Stroke Spring Force, 360 psi Initial Charge
Item #: 69129724
Brand: Associated Spring Raymond
Model #: X6600-080
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Initial Charge Pressure (psi) | 360 |
| Initial Charge Pressure (bar) | 25 |
| Diameter (mm) | 120.20 |
| Body Length (mm) | 148 |
| Body Length (Decimal Inch) | 5.8268 |
| Diameter (Decimal Inch) | 4.7323 |
| Spring Force Initial (lbf) | 14905 |
| Spring Force Full Stroke (lbf) | 23400 |
| Rod Diameter (mm) | 75 |
| Rod Diameter (Decimal Inch) | 2.9528 |
| Overall Length (mm) | 228 |
| Overall Length (Decimal Inch) | 8.9764 |
| Maximum Stroke (mm) | 80 |
| Maximum Stroke (Decimal Inch) | 3.1496 |
