Iscar - 1.1811" Blade Height, 0.1575" Blade Width, 1.9882" OAL, Neutral Cut, Double End Indexable Cut-Off Blade - HGAD Blade
Item #: 70023932
Brand: Iscar
Model #: 2301458
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Single or Double End | Double |
| Cutting Direction | Neutral |
| Blade Height (mm) | 30.00 |
| Blade Height (Decimal Inch) | 1.1811 |
| Blade Width (mm) | 4.00 |
| Blade Width (Decimal Inch) | 0.1575 |
| Blade Overall Length (mm) | 50.50 |
| Blade Overall Length (Decimal Inch) | 1.9882 |
| Blade Style | HGAD |
| Insert Holding Method | Self Grip |
| Maximum Workpiece Diameter (Decimal Inch) | 1.9700 |
| Cutting Height (mm) | 24.00 |
| Cutting Height (Decimal Inch) | 0.9449 |
| Minimum Insert Width (mm) | 3.00 |
| Minimum Insert Width (Decimal Inch) | 0.1181 |
| Maximum Insert Width (mm) | 3.00 |
| Maximum Insert Width (Decimal Inch) | 0.1181 |
