Riten - 1.289" Head Diam, Carbide-Tipped Steel Standard Point Half Dead Center - B&S 10 Brown & Sharpe Taper, 1.289" Point Diam, 8-9/16" OAL
Item #: 70566161
Brand: Riten
Model #: 74004
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Center Type | Half Center |
| Shank Type | Brown & Sharpe Taper |
| Shank Taper Size | B&S 10 |
| Point Style | Standard Point |
| Carbide-Tipped | Yes |
| Head Diameter (Decimal Inch) | 1.2890 |
| Point Diameter (Decimal Inch) | 1.2890 |
| Tip Diameter (Inch) | 1/2 |
| Taper Length (Inch) | 5-11/16 |
| Taper Length (Decimal Inch) | 5.6875 |
| Overall Length (Inch) | 8-9/16 |
| Knockout Diameter (Decimal Inch) | 1.0450 |
| Point to Gauge Line (Inch) | 2-7/8 |
| Cutout Length (Inch) | 2-1/4 |
