Indexable Drill Inserts; Insert Style: DFPR; Insert Material: Carbide; Manufacturer Grade: KCU40; Thickness (mm): 2
Item #: 02351211
Brand: Kennametal
Model #: 7034332
Product Specifications
| Insert Style | DFPR |
| Insert Material | Carbide |
| Manufacturer Grade | KCU40 |
| Thickness (mm) | 2 |
| Inscribed Circle (Decimal Inch) | 0.1810 |
| Inscribed Circle (mm) | 4.60 |
| Corner Radius (Decimal Inch) | 0.0160 |
| Corner Radius (mm) | 0.4 |
| Chipbreaker | LC |
| Series | Drill Fix |
| Shape | Proprietary |
| Relief Angle | 11 |
| Ansi Code | DFPR040204LCO |
| Iso Code | DFPR040204LCO |
| Compatible Drill Style | DFPR |
| Insert Size | 04 |
| Width (mm - 2 Decimals) | 4.6 |
| Length (Mm) | 4.60 |
| Width (Decimal Inch - 4 Decimals) | 0.016 |
| Length (Decimal Inch - 4 Decimals) | 0.016 |
| Included Angle Degree | 11 |
| Coating/Finish | AlTiN; TiN |
| Insert Size Code | 04 |
| UNSPSC Code | 23242105 |
