3M - 35 Piece, Black, Blue, Clear, Green, Red, White and Yellow, Heat Shrink Electrical Tubing Kit
Item #: 73125619
Brand: 3M
Model #: 7000031556
| Product Specifications | |
|---|---|
| Number of Pieces | 35 |
| Color | Black; Blue; Clear; Green; Red; White; Yellow |
| Inside Diameter Before Shrinking (mm) | 2.36 |
| Inside Diameter Before Shrinking (Inch) | 0.0930; 3/32 |
| Inside Diameter Before Shrinking (Decimal Inch) | 0.0930; 3/32 |
| Inside Diameter After Shrinking (mm) | 1.17 |
| Inside Diameter After Shrinking (Decimal Inch) | 0.0460 |
| Shrink Ratio | 2:1 |
| Shrink Temperature (F) | 212 |
| Resistance Features | Corrosion Resistant; Fire Resistant; Fungus Resistant; Solvent Resistant; Split Resistant |
| Material | Polyolefin |
| Includes | (5) Black; (5) Blue; (5) Clear; (5) Green; (5) Red; (5) White; (5) Yellow |
| Tubing Length (Inch) | 6 |
| Wall Thickness After Shrinking (mm) | 0.51 |
| Wall Thickness After Shrinking (Decimal Inch) | 0.0200 |
| Maximum Compatible Wire Size (AWG) | 20 |
| Minimum Compatible Wire Size (AWG) | 22 |
| Maximum Operating Temperature (F) | 275 |
| Minimum Operating Temperature (F) | -67 |
| Standards Met | ABS Type Approved; AMS3636; AMS3637; CSA Certified; CSA LR38227; MIL-DTL-23053/5 Class 1 & Class 2; UL Recognized File E39100 |
