Cooper Bussmann - 250 VAC, 32 VDC, 0.125 Amp, Fast-Acting Miniature Glass Fuse - 15mm OAL, 10 at 125 V kA Rating, 5mm Diam - Exact Tooling

Cooper Bussmann - 250 VAC, 32 VDC, 0.125 Amp, Fast-Acting Miniature Glass Fuse - 15mm OAL, 10 at 125 V kA Rating, 5mm Diam


Item #: 71924724
Brand: Cooper Bussmann
Model #: BK-C520-125-R
Exact Tooling IR#: 04

Features and Benefits

Miniature glassfuses are constructed of a conductive metal placed on a small glass body. Fuses with glass bodies are easier to see if they are blown. They are commonly used in appliances and electronics.
Fast acting fuses refer to the amount of time that a fuse can withstand a current before overload. They are used to protect sensitive equipment.
Product Specifications
Fuse Type Miniature Glass
Amperage (mA) 125
Amperage 0.125
Voltage 250 VAC; 32 VDC
Fuse Timing Fast-Acting
Fuse Body Type Cartridge
Overall Length (mm) 15
Overall Length (Decimal Inch) 0.5910
Overall Diameter (mm) 5.00
Overall Diameter (Decimal Inch) 0.1970
Material Glass
Interrupting Rating (A) 10000 @ 125 V; 35 @ 250 V
Interrupting Rating (kA) 10 @ 125 V
Standards Met CSA Class 1422-01 File 53787 Certified; RoHS 2002/95/EC; UL Listed 248-14; UL Listed Guide JDYX File E19180
