Mahr - Electronic Calipers; Minimum Measurement (mm): 0.00 ; Minimum Measurement (Decimal Inch): 0.0000 ; Maximum Measurement (Decimal Inch): 30 ; Maximum Measurement (mm): 750.00 ; Accuracy Plus/Minus (Decimal Inch): 0.0020 ; Accuracy Plus/Minus (mm): 0
Item #: 73854937
Brand: Mahr
Model #: 4112714
Product Specifications
Electronic Calipers; Minimum Measurement (mm): 0.00 ; Minimum Measurement (Decimal Inch): 0.0000 ; Maximum Measurement (Decimal Inch): 30 ; Maximum Measurement (mm): 750.00 ; Accuracy Plus/Minus (Decimal Inch): 0.0020 ; Accuracy Plus/Minus (mm): 0.0500
| Minimum Measurement (mm) | 0.00 |
| Minimum Measurement (Decimal Inch) | 0.0000 |
| Maximum Measurement (Decimal Inch) | 30 |
| Maximum Measurement (mm) | 750.00 |
| Accuracy Plus/Minus (Decimal Inch) | 0.0020 |
| Accuracy Plus/Minus (mm) | 0.0500 |
| Resolution (Decimal Inch) | 0.0005 |
| Resolution (mm) | 0.0100 |
| IP Rating | IP65 |
| Data Output | Digimatic; Opto RS-232C; USB; Wireless |
| Calibrated | No |
| Traceability Certification Included | No |
| Jaw Length (mm) | 150.00 |
| Includes Inside Diameter Jaws | Yes |
| Jaw Style | Inside/Outside |
| Material | Stainless Steel |
| Jaw Material | Stainless Steel |
| Power Source | Battery |
| Battery Type | 3 Volt Lithium CR2032 |
| Minimum Inside Diameter Measurement (Inch) | 0.0000 |
| Minimum Inside Diameter Measurement (mm) | 0.00 |
| Minimum Inside Diameter Measurement (Decimal Inch) | 0.0000 |
| Additional Information | Model Number: 18 EWR; Length: 905 mm; Scale Width: 25 mm; Nib Height: 20 mm; Upper Jaw Size: 55 mm; Height of Digits: 12.5 mm; Battery life: Approx. 3 yr; Function: AUTO-ON/OFF, DATA (Data Transmission Via Connection Cable), ON/OFF, PRESET (For Entering a |
| Maximum Inside Diameter Measurement (Inch) | 30 |
| Maximum Inside Diameter Measurement (mm) | 750.00 |
| Trade Name | MarCal |
| Nib Size (mm) | 20.00 |
| Includes | Battery; Case; Instruction Manual |
