Cooper Bussmann - 170 VDC, 600 VAC, 4 Amp, Time Delay Size Rejecting/NonRejecting Fuse - Fuse Holder Mount, 1-5/16" OAL, 10 at DC, 100 at AC (RMS) kA Rating, 13/32" Diam
Item #: 74700949
Brand: Cooper Bussmann
Model #: SC-4
Exact Tooling IR#: 04
Features and Benefits
Size rejecting/non rejecting fuses are designed to prevent fuses from being used with the incorrect size as well as prevent a low interrupting rating from being used in a circuit that needs a higher rating.
Time delay fuses, also known as duel-element fuses, are designed to allow for a surge in electricity during a short time before overloading or shorting out. They can protect equipment from overload and allow for greater starting amperage.
| Product Specifications | |
|---|---|
| Fuse Type | Size Rejecting/NonRejecting |
| Fuse Class | G |
| Amperage | 4 |
| Voltage | 170 VDC; 600 VAC |
| Fuse Timing | Time Delay |
| Fuse Body Type | Cartridge |
| Overall Length (mm) | 33.30 |
| Overall Length (Inch) | 1-5/16 |
| Overall Length (Decimal Inch) | 1.3100 |
| Overall Diameter (mm) | 10.41 |
| Overall Diameter (Inch) | 13/32 |
| Overall Diameter (Decimal Inch) | 0.4100 |
| Mounting Type | Fuse Holder |
| Rejection Setting | Rejecting |
| Interrupting Rating (kA) | 10 @ DC; 100 @ AC (RMS) |
| Standards Met | CE Certified; CSA C22.2 No. 248.5 Class 1422-01 File 53787 Certified; RoHS Compliant; UL Listed 248-5 Class G Guide JDDZ File E4273 |
