Iscar - 9 Inserts, 2" Cut Diam, 3/4" Arbor Diam, 0.303" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0/90° Lead Angle, 1.57" High, HP AN.. 0702.. Insert Compatibility, Series Heliplus
Item #: 75755058
Brand: Iscar
Model #: 3104163
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 2.0000 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Lead Angle | 0/90 |
| Overall Height (Decimal Inch) | 1.5700 |
| Insert Compatibility | HP AN.. 0702.. |
| Series | Heliplus |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.3030 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 9 |
| Insert Holding Method | Screw |
| Cutter Style | HP F90AN-07 |
| Number of Flutes | 9 |
| Pitch | Fine |
| Complete Insert Compatibility | HP ANCR 070204PNFR; HP ANCR 070204PNFR-P; HP ANCT 070202 PN-R; HP ANCT 070204PN-R; HP ANKT 0702 PN-R; HP ANKT 070202PNTR; HP ANKT 0702PNTR; HP ANKW 070204PNTR |
