Seco - 4 Inserts, 40mm Cut Diam, 16mm Arbor Diam, 8mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 90° Lead Angle, 40mm High, SONX 09T3 Insert Compatibility, Series Mini Square
Item #: 77893147
Brand: Seco
Model #: 69190
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 40.00 |
| Cutting Diameter (Decimal Inch) | 1.5748 |
| Arbor Hole Diameter (mm) | 16.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.6299 |
| Lead Angle | 90 |
| Overall Height (mm) | 40.00 |
| Overall Height (Decimal Inch) | 1.5748 |
| Insert Compatibility | SONX 09T3 |
| Series | Mini Square |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 8.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3150 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutting Rake Angle | -9 |
| Rake | Negative |
| Hub Diameter (mm) | 35.00 |
| Hub Diameter (Decimal Inch) | 1.3780 |
| Keyway Width (mm) | 8.40 |
| Keyway Width (Decimal Inch) | 0.3307 |
| Maximum RPM | 16600 |
| Pitch | Close |
| Complete Insert Compatibility | SONX 09T304TR-M10; SONX 09T304TR-ME06; SONX 09T308TR-M10 |
