Screw Machine Length Drill Bit: 0.1378″ Dia, 130 °, High Speed Steel Coated, Right Hand Cut, Spiral Flute, Straight-Cylindrical Shank, Series A520
Item #: 78090602
Brand: DORMER
Model #: 5970567
Product Specifications
| Drill Bit Size (mm) | 3.50 |
| Tool Material | High Speed Steel |
| Cutting Direction | Right Hand |
| Coating/Finish | Coated |
| Drill Point Angle | 130 |
| Spiral Type | Regular |
| Flute Type | Spiral |
| Point Type | ADX |
| Coolant Through | No |
| Shank Type | Straight-Cylindrical |
| Shank Diameter (Decimal Inch) | 0.1378 |
| Drill Bit Size (Decimal Inch) | 0.1378 |
| Overall Length (mm) | 52.00 |
| Overall Length (Decimal Inch) | 2.0472 |
| Series | A520 |
| Web Thinning | Web-Thinned |
| Web Configuration | Parallel |
| Drill Length Type | Screw Machine |
| Shank Length (Decimal Inch) | 1.2598 |
| Shank Length (mm) | 32.00 |
| Flute By Diameter Ratio | 2.5xD |
| Tool Performance | High Performance |
| Standards | DIN 1897 |
| Flute Length (mm) | 20.00 |
| Drill Bit Grade | Heavy Duty |
| Drill Bit Size Range (Decimal Inch) | 0.1000 to 0.1500 |
| Drill Bit Size Range (mm) | 3.50 to 5.00 |
| Specification Number | DIN 1897 |
| Specification Designation | DIN |
