Norton - 20" Diam x 8" Hole x 3" Wide Centerless & Cylindrical Grinding Wheel - 46 Grit, Silicon Carbide, Type 7, Coarse Grade, Vitrified Bond, Two Side Recess
Item #: 81163842
Brand: Norton
Model #: 66253246972
Exact Tooling IR#: 04
Features and Benefits
Two Sides Recessed
Harder than ceramic, silicon carbide is a fast cutting abrasive. Commonly used on nonferrous metals and in low-pressure applications.
Vitrified bonds are made from a mixture of clays fused at high temperatures, creating a glass bond.
| Product Specifications | |
|---|---|
| Wheel Diameter (Inch) | 20 |
| Wheel Width (Inch) | 3 |
| Hole Size (Inch) | 8 |
| Wheel Type Number | Type 7 |
| Abrasive Material | Silicon Carbide |
| Grade | Coarse |
| Grit | 46 |
| Wheel Hardness | G |
| Bond Type | Vitrified |
| Recess Type | Two-Side |
| Porosity | Non-Porous |
| Recess Diameter (Inch) | 11-1/2 |
| Recess Depth (Inch) | 1/2 |
| Grain Structure | 8 |
| Opposite Side Recess Depth (Inch) | 1/2 |
| Opposite Side Recess Diameter (Inch) | 11-1/2 |
| Specification | 73C46-I8VX |
| Wheel Color | Brown |
| Maximum RPM | 1625 |
| Wheel Hardness Rating | Soft |
