Gardner Spring - 2-1/2" Bolt, 2-9/16" ID, Grade 1095 Chrome Vanadium Steel, Belleville Disc Spring - 5" OD, 0.387" High, 9/32" Thick
Item #: 81433815
Brand: Gardner Spring
Model #: MG5000-281
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 2-1/2 |
| System of Measurement | Inch |
| Inside Diameter (Decimal Inch) | 2.5620 |
| Material | Chrome Vanadium Steel |
| Material Grade | 1095 |
| Outside Diameter (Decimal Inch) | 5.0000 |
| Thickness (Decimal Inch) | 0.2810 |
| Overall Height (Decimal Inch) | 0.3870 |
| Deflection (Decimal Inch) | 0.0848 |
| Deflection to Flat (Decimal Inch) | 0.0850 |
| Minimum Inside Diameter (Decimal Inch) | 2.5620 |
| Load at Flat (Lb.) | 18316.80 |
| Load at Flat (N) | 81340.00 |
| Load at Deflection (Lb.) | 14936.00 |
| Minimum Load at Deflection (Lb.) | 12668.00 |
| Minimum Load at Deflection (N) | 56350.00 |
| Maximum Load at Deflection (Lb.) | 17139.00 |
| Maximum Load at Deflection (N) | 76238.00 |
