Guhring - 2.17mm 118° High Speed Steel Jobber Drill - Exact Tooling

Guhring - 2.17mm 118° High Speed Steel Jobber Drill


Item #: 55065973
Brand: Guhring
Model #: 9002050021700

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (mm) 2.17
Drill Bit Size (Decimal Inch) 0.0854
Drill Point Angle 118
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Bright
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (mm) 27.00
Overall Length (mm) 53.00
Flute Length x Diameter Ratio 5xD
Point Type Standard
Shank Diameter (mm) 2.17
Shank Diameter (Decimal Inch) 0.0854
Spiral Type Regular Spiral
Specification Designation DIN
Web Configuration Tapered
Drill Bit Diameter Tolerance (mm) +0.000 to -0.014
Specification Number DIN 338
Material Grade M2
Series/List 205
$ 2.46

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
