Iscar - 1-1/4" Cut Diam, 0.06" Max Depth, 1" Shank Diam, Weldon Shank Indexable High-Feed End Mill - Screw Holding Method, FF WOMT Insert, FF EW Toolholder, Through Coolant
Item #: 84315209
Brand: Iscar
Model #: 3103449
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 1.2500 |
| Maximum Depth of Cut (Decimal Inch) | 0.0600 |
| Shank Type | Weldon |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Number of Cutter Inserts | 3 |
| Insert Style | FF WOMT |
| Toolholder Style | FF EW |
| Insert Holding Method | Screw |
| Weldon Flat | Yes |
| End Mill Type | End Mill |
| Number of Flutes | 3 |
| Minimum Cutting Diameter (Decimal Inch) | 0.7000 |
| Through Coolant | Through Coolant |
| Maximum Cutting Diameter (Decimal Inch) | 1.2500 |
| Overall Length (Decimal Inch) | 6.7600 |
