Kennametal - CAT50 Taper Shank 3/4" Hole End Mill Holder/Adapter - 1-3/4" Nose Diam, 3-3/4" Projection, 1-8 Drawbar, Through-Spindle Coolant
Item #: 84905595
Brand: Kennametal
Model #: 1026250
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Taper Shank |
| Taper Size | CAT50 |
| Hole Diameter (Inch) | 3/4 |
| Nose Diameter (Inch) | 1-3/4 |
| Projection (Decimal Inch) | 3.7500 |
| Through Coolant | Yes |
| Clamping Depth (Decimal Inch) | 5.9400 |
| Overall Length (Decimal Inch) | 7.7500 |
| Balanced to (RPM) | 12000 |
| Coolant Type | Through-Spindle |
| Drawbar Thread Size | 1-8 |
