Allied Machine and Engineering - 5/8" 140° Spiral Flute Solid Carbide Taper Length Drill Bit
Item #: 04596821
Brand: Allied Machine and Engineering
Model #: 390E06250A21M
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Multilayer coating is a proprietary coating exclusive to Allied Machine & Engineering Corp.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (Inch) | 5/8 |
| Drill Bit Size (Decimal Inch) | 0.6250 |
| Drill Point Angle | 140 |
| Drill Bit Material | Solid Carbide |
| Drill Bit Finish/Coating | Multilayer |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Through Coolant | Yes |
| Point Type | Standard |
| Overall Length (Decimal Inch) | 8.5400 |
| Spiral Type | Regular Spiral |
| Shank Diameter (mm) | 16.00 |
| Maximum Drilling Depth (Decimal Inch) | 5.6690 |
| Shank Length (mm) | 48 |
| Drill Point Length (Decimal Inch) | 0.1000 |
| Web Configuration | Tapered |
| Web Thinning | Web-Thinned |
| Series/List | ASC320 |
