Iscar - Arbor Hole Connection, 3/16" Cutting Width, 0.7" Depth of Cut, 3" Cutter Diam, 1" Hole Diam, 10 Tooth Indexable Slotting Cutter - SDN-LN08 Toolholder, LNET Insert, Right Hand Cutting Direction
Item #: 85438885
Brand: Iscar
Model #: 3105578
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (Decimal Inch) | 0.1870 |
| Maximum Depth of Cut (Decimal Inch) | 0.7000 |
| Cutter Diameter (Decimal Inch) | 3.0000 |
| Hole Diameter (Decimal Inch) | 1.0000 |
| Number of Teeth | 10 |
| Toolholder Style | SDN-LN08 |
| Series | Mini-TangSlot(SDN-LN08) |
| Insert Style | LNET |
| Number of Cutter Inserts | 10 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Minimum Cutting Width (Decimal Inch) | 0.1870 |
| Maximum Cutting Width (Decimal Inch) | 0.2070 |
| Hub Diameter (Decimal Inch) | 1.5000 |
| Cutting Radius (Inch) | 1/64 |
| Complete Insert Compatibility1 | LNET 083004-TN-N; LNET 083204-TN-N |
