Tritan - 1-5/8" ID, 7.4803" OAL x 4.1732" OAH Pillow Block - 4,631 Lb Static Cap, 5,206 Lb Dyn Cap, 5-3/4" Btw Mnt Hole Ctrs, 2-1/8" Base-to-Ctr Ht, Cast Iron/Steel
Item #: 87052346
Brand: Tritan
Model #: UCP209-26
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Pillow Block |
| Inside Diameter (Decimal Inch) | 1.6250 |
| Inside Diameter (Inch) | 1-5/8 |
| Width (Decimal Inch) | 2.1260 |
| Overall Length (Decimal Inch) | 7.4803 |
| Overall Height (Decimal Inch) | 4.1732 |
| Static Load Capacity (Pounds) | 4631.00 |
| Dynamic Load Capacity (Pounds) | 5206 |
| Distance Between Mounting Hole Centers (Decimal Inch) | 5.7500 |
| Material | Cast Iron/Steel |
| Distance Between Base And Center (Decimal Inch) | 2.1250 |
| Insert Material | 52100 Steel |
| Lock Type | Set Screw |
| Bolt Size (Inch) | 1/2 |
| Metric Bolt Size | 14.0000 |
