Iscar - Arbor Hole Connection, 0.139" Cutting Width, 0.63" Depth of Cut, 3.15" Cutter Diam, 1" Hole Diam, 10 Tooth Indexable Slotting Cutter - SGSA Toolholder, GSAN 4 Insert, Right Hand Cutting Direction
Item #: 87109294
Brand: Iscar
Model #: 2301846
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (Decimal Inch) | 0.1390 |
| Maximum Depth of Cut (Decimal Inch) | 0.6300 |
| Cutter Diameter (Decimal Inch) | 3.1500 |
| Hole Diameter (Decimal Inch) | 1.0000 |
| Number of Teeth | 10 |
| Toolholder Style | SGSA |
| Series | Self-Grip(SGSA) |
| Insert Style | GSAN 4 |
| Staggered Tooth | No |
| Number of Cutter Inserts | 10 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 995 |
| Minimum Cutting Width (Decimal Inch) | 0.1390 |
| Maximum Cutting Width (Decimal Inch) | 0.1780 |
| Cutting Radius (Inch) | 1/64 |
| Cutter Body Width (Decimal Inch) | 0.1260 |
| Complete Insert Compatibility1 | GSAN 4 |
