Kennametal - 1-1/4" Cut Diam, 0.6" Max Depth of Cut, 1-1/4" Shank Diam, 3.93" OAL, Indexable Square Shoulder End Mill - AP.T 1604.., AP.W 1604.., APEX 1604.. Inserts, Cylindrical Shank, Through Coolant
Item #: 87927737
Brand: Kennametal
Model #: 5672223
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 1.2500 |
| Cutting Diameter (Inch) | 1-1/4 |
| Shank Type | Cylindrical |
| Shank Diameter (Inch) | 1-1/4 |
| Shank Diameter (Decimal Inch) | 1.2500 |
| Overall Length/Projection (Decimal Inch) | 3.9300 |
| Through Coolant | Coolant Through |
| Maximum Depth of Cut (Decimal Inch) | 0.6000 |
| Number of Cutter Inserts | 3 |
| Insert Holding Method | Screw |
| End Mill Type | End Mill |
| Cutter Style | 7690 VA 16 |
| Number of Flutes | 3 |
| Head Length (Decimal Inch) | 1.6000 |
| Weldon Flat | Yes |
| Insert Compatibility | AP.T 1604.., AP.W 1604.., APEX 1604.. |
| Toolholder Material | Tool Steel |
