Kennametal - 3° Lead Angle, 39.62mm Max Cut Diam, 0.3" Max Depth of Cut, Indexable Chamfer & Angle End Mill - 3 Inserts, OD.T 0404.., ODMW 0404.. Insert Style, 3.77" OAL, Through Coolant, Straight Shank
Item #: 87927794
Brand: Kennametal
Model #: 5672110
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Maximum Cutting Diameter (mm) | 39.62 |
| Maximum Cutting Diameter (Decimal Inch) | 1.5600 |
| Shank Type | Weldon |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 3 |
| Overall Length (Decimal Inch) | 3.7700 |
| Insert Style | OD.T 0404.., ODMW 0404.. |
| Through Coolant | Yes |
| Maximum Depth of Cut (Decimal Inch) | 0.3000 |
| Number of Cutter Inserts | 3 |
| Insert Holding Method | Screw |
| Toolholder Style | 7745 VOD 04 |
| Number of Flutes | 3 |
| Weldon Flat | Yes |
| Toolholder Material | Tool Steel |
