Iscar - Arbor Hole Connection, 0.106" Cutting Width, 1" Depth of Cut, 4.92" Cutter Diam, 1-1/4" Hole Diam, 16 Tooth Indexable Slotting Cutter - SGSA Toolholder, GSAN 3 Insert, Right Hand Cutting Direction
Item #: 91105809
Brand: Iscar
Model #: 2301848
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (Decimal Inch) | 0.1060 |
| Maximum Depth of Cut (Decimal Inch) | 1.0000 |
| Cutter Diameter (Decimal Inch) | 4.9200 |
| Hole Diameter (Decimal Inch) | 1.2500 |
| Number of Teeth | 16 |
| Toolholder Style | SGSA |
| Series | Self-Grip(SGSA) |
| Insert Style | GSAN 3 |
| Staggered Tooth | No |
| Number of Cutter Inserts | 16 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 635 |
| Minimum Cutting Width (Decimal Inch) | 0.1060 |
| Maximum Cutting Width (Decimal Inch) | 0.1380 |
| Cutting Radius (Inch) | 1/64 |
| Cutter Body Width (Decimal Inch) | 0.0940 |
| Complete Insert Compatibility1 | GSAN 3 |
