Iscar - 212.5mm Cut Diam, 60mm Arbor Hole, 4.6mm Max Depth of Cut, 42° Indexable Chamfer & Angle Face Mill - 12 Inserts, OF..\xB6RFM. 1905 Insert, Right Hand Cut, 12 Flutes, Series Heliocto
Item #: 91122218
Brand: Iscar
Model #: 3104285
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 212.50 |
| Arbor Hole Diameter (mm) | 60.00 |
| Lead Angle | 42 |
| Overall Height (mm) | 63.00 |
| Insert Compatibility | OF..; RFM. 1905 |
| Series | Heliocto |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 4.60 |
| Number of Cutter Inserts | 12 |
| Insert Holding Method | Screw |
| Cutter Style | HOF |
| Number of Flutes | 12 |
| Keyway Width (mm) | 25.70 |
| Maximum Body Diameter (Decimal Inch) | 7.8740 |
| Cutting Direction | Right Hand |
| Maximum Insert Radius (Decimal Inch) | 0.0630 |
| Counterbore Diameter (Decimal Inch) | 3.5430 |
| Complete Insert Compatibility | OFCR/OFCT-AEN/AETN; OFCT/OFCR-RW/AER (Wiper); OFMT 07; OFMW-AETN; OFMW-FF; RFMT 1905-76; RFMW 1905 |
