Iscar - 112mm Cut Diam, 32mm Arbor Hole, 5.5mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 7 Inserts, ONH.. Insert, Right Hand Cut, 7 Flutes, Series 16Mill
Item #: 91122416
Brand: Iscar
Model #: 3103315
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 112.00 |
| Arbor Hole Diameter (mm) | 32.00 |
| Lead Angle | 45 |
| Overall Height (mm) | 50.00 |
| Insert Compatibility | ONH.. |
| Series | 16Mill |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 5.50 |
| Number of Cutter Inserts | 7 |
| Insert Holding Method | Screw |
| Cutter Style | F45NM |
| Number of Flutes | 7 |
| Keyway Width (mm) | 14.40 |
| Maximum Body Diameter (Decimal Inch) | 3.9370 |
| Cutting Direction | Right Hand |
| Maximum Insert Radius (Decimal Inch) | 0.0510 |
| Counterbore Diameter (Decimal Inch) | 1.6930 |
| Complete Insert Compatibility | ONHQ-TN; ONHU 0806-N-PL; ONHU 0806AN-W; ONHU/ONMU 080608 AN-N-HP; ONHU/ONMU-08-TN-MM; ONHU/ONMU-08-TN/HL |
