Iscar - 5 Inserts, 80mm Cut Diam, 27mm Arbor Diam, 13mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0/90° Lead Angle, 50mm High, HM390 TDKT 1505 Insert Compatibility, Through Coolant, Series HeliIQMill
Item #: 91165605
Brand: Iscar
Model #: 3106399
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 80.00 |
| Arbor Hole Diameter (mm) | 27.00 |
| Lead Angle | 0/90 |
| Overall Height (mm) | 50.00 |
| Insert Compatibility | HM390 TDKT 1505 |
| Series | HeliIQMill |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 13.00 |
| Number of Cutter Inserts | 5 |
| Insert Holding Method | Screw |
| Cutter Style | HM390 FTD-15 |
| Number of Flutes | 5 |
| Hub Diameter (mm) | 74.00 |
| Keyway Width (mm) | 12.40 |
| Counterbore Diameter (Decimal Inch) | 0.7870 |
| Complete Insert Compatibility | HM390 TDKT 1505 |
