Iscar - 8 Inserts, 80mm Cut Diam, 32mm Arbor Diam, 9mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0/90° Lead Angle, 50mm High, XCMT Insert Compatibility, Through Coolant, Series IscarPlunger
Item #: 91167189
Brand: Iscar
Model #: 3103129
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 80.00 |
| Arbor Hole Diameter (mm) | 32.00 |
| Lead Angle | 0/90 |
| Overall Height (mm) | 50.00 |
| Insert Compatibility | XCMT |
| Series | IscarPlunger |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 9.00 |
| Number of Cutter Inserts | 8 |
| Insert Holding Method | Screw |
| Cutter Style | PLX |
| Number of Flutes | 8 |
| Hub Diameter (mm) | 68.00 |
| Keyway Width (mm) | 14.40 |
| Maximum Body Diameter (Decimal Inch) | 2.6770 |
| Cutting Edge Length (Decimal Inch) | 0.3540 |
| Counterbore Diameter (Decimal Inch) | 1.0630 |
| Complete Insert Compatibility | XCMT-TR |
