McGill - 5/8" Roller Diam x 7/16" Width, 1/4" Stud Diam x 3/4" Length, Sealed Stud Cam Follower - Steel, 5/16" Thread Length, 1/4-28 Thread, 1.06" OAL, 930 Lb Dynamic Cap, 1,085 Lb Static Cap
Item #: 92609569
Brand: McGill
Model #: CF 5/8 N S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower |
| Roller Diameter (Decimal Inch) | 0.6250 |
| Roller Diameter (Inch) | 5/8 |
| Roller Width (Decimal Inch) | 0.4060 |
| Roller Width (Inch) | 7/16 |
| Stud Diameter (Decimal Inch) | 0.2500 |
| Dynamic Load Capacity (Lb.) | 930 |
| Dynamic Load Capacity (N) | 4137 |
| Static Load Capacity (Pounds) | 1085.00 |
| Static Load Capacity | 4826 |
| Length (Decimal Inch) | 1.060 |
| Thread Size | 1/4-28 |
| Material | Steel |
| Stud Length (Decimal Inch) | 0.7500 |
| Stud Length (Inch) | 3/4 |
| Thread Length (Inch) | 5/16 |
| McGill Part Number | CF 5/8 N S |
| Roller Type | Needle Roller |
