McGill - 4-1/2" Roller Diam x 2" Width, 1-1/8" Stud Diam x 2-1/2" Length, V Guide Roller - Steel, 1-3/4" Thread Length, 1-1/4-12 Thread, 4-1/2" OAL, 14,300 Lb Dynamic Cap, 16,000 Lb Static Cap
Item #: 92609833
Brand: McGill
Model #: VCF 4 1/2
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | V-Guide Roller |
| Roller Diameter (Decimal Inch) | 4.5000 |
| Roller Diameter (Inch) | 4-1/2 |
| Roller Width (Decimal Inch) | 2.0000 |
| Roller Width (Inch) | 2 |
| Stud Diameter (Decimal Inch) | 1.2500 |
| Dynamic Load Capacity (Lb.) | 14300 |
| Dynamic Load Capacity (N) | 63610 |
| Static Load Capacity (Pounds) | 16000.00 |
| Static Load Capacity | 71168 |
| Length (Decimal Inch) | 4.500 |
| Thread Size | 1-1/4-12 |
| Material | Steel |
| Stud Length (Decimal Inch) | 2.5000 |
| Stud Length (Inch) | 2-1/2 |
| Point Diameter (Inch) | 3 |
| Thread Length (Inch) | 1-3/4 |
| Hex Size (Inch) | 7/16 |
| McGill Part Number | VCF 4 1/2 |
| Roller Type | Tapered |
