McGill - 2-1/2" Roller Diam x 1-11/16" Width, 1" Stud Diam x 2-1/4" Length, Flanged Load Roller - Steel, 1-1/2" Thread Length, 1-14 Thread, 3.94" OAL, 5,120 Lb Dynamic Cap, 3,120 Lb Static Cap
Item #: 92609932
Brand: McGill
Model #: FCF 2 1/2
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Flanged Load Roller |
| Roller Diameter (Decimal Inch) | 2.5000 |
| Roller Diameter (Inch) | 2-1/2 |
| Roller Width (Decimal Inch) | 1.6880 |
| Roller Width (Inch) | 1-11/16 |
| Stud Diameter (Decimal Inch) | 1.0000 |
| Dynamic Load Capacity (Lb.) | 5120 |
| Dynamic Load Capacity (N) | 22774 |
| Static Load Capacity (Pounds) | 3120.00 |
| Static Load Capacity | 13878 |
| Length (Decimal Inch) | 3.940 |
| Thread Size | 1-14 |
| Material | Steel |
| Flange Diameter (Decimal Inch) | 3.1900 |
| Flange Thickness (Decimal Inch) | 0.5900 |
| Stud Length (Decimal Inch) | 2.2500 |
| Stud Length (Inch) | 2-1/4 |
| Thread Length (Inch) | 1-1/2 |
| Hex Size (Inch) | 7/16 |
| McGill Part Number | FCF 2 1/2 |
| Roller Type | Ball Bearing |
