McGill - 3/4" Roller Diam x 1/2" Width, 3/8" Stud Diam x 7/8" Length, Sealed Stud Cam Follower with Hex - Steel, 3/8" Thread Length, 3/8-24 Thread, 1.41" OAL, 1,660 Lb Dynamic Cap, 2,065 Lb Static Cap
Item #: 92610559
Brand: McGill
Model #: CF 3/4 SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower with Hex |
| Roller Diameter (Decimal Inch) | 0.7500 |
| Roller Diameter (Inch) | 3/4 |
| Roller Width (Decimal Inch) | 0.5000 |
| Roller Width (Inch) | 1/2 |
| Stud Diameter (Decimal Inch) | 0.3750 |
| Dynamic Load Capacity (Lb.) | 1660 |
| Dynamic Load Capacity (N) | 7384 |
| Static Load Capacity (Pounds) | 2065.00 |
| Static Load Capacity | 9185 |
| Length (Decimal Inch) | 1.410 |
| Thread Size | 3/8-24 |
| Material | Steel |
| Stud Length (Decimal Inch) | 0.8750 |
| Stud Length (Inch) | 7/8 |
| Thread Length (Inch) | 3/8 |
| McGill Part Number | CF 3/4 SB |
| Roller Type | Needle Roller |
