McGill - 1-1/4" Roller Diam x 3/4" Width, 1/2" Stud Diam x 1-1/4" Length, Crowned Sealed Stud Cam Follower with Hex - Steel, 5/8" Thread Length, 1/2-20 Thread, 2.03" OAL, 3,930 Lb Dynamic Cap, 4,250 Lb Static Cap
Item #: 92611078
Brand: McGill
Model #: CCF 1 1/4 SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Crowned Sealed Stud Cam Follower with Hex |
| Roller Diameter (Decimal Inch) | 1.2500 |
| Roller Diameter (Inch) | 1-1/4 |
| Roller Width (Decimal Inch) | 0.7500 |
| Roller Width (Inch) | 3/4 |
| Stud Diameter (Decimal Inch) | 0.5000 |
| Dynamic Load Capacity (Lb.) | 3930 |
| Dynamic Load Capacity (N) | 17481 |
| Static Load Capacity (Pounds) | 4250.00 |
| Static Load Capacity | 18904 |
| Length (Decimal Inch) | 2.030 |
| Thread Size | 1/2-20 |
| Material | Steel |
| Stud Length (Decimal Inch) | 1.2500 |
| Stud Length (Inch) | 1-1/4 |
| Thread Length (Inch) | 5/8 |
| McGill Part Number | CCF 1 1/4 SB |
| Roller Type | Needle Roller |
