Tritan - 70mm ID, 266mm OAL x 156mm OAH Pillow Block - 10,116 Lb Static Cap, 13,668 Lb Dyn Cap, 8.27" Btw Mnt Hole Ctrs, 79.375mm Base-to-Ctr Ht, Cast Iron/Steel
Item #: 92647924
Brand: Tritan
Model #: UCP214-70MM
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Pillow Block |
| Inside Diameter (mm) | 70.0000 |
| Width (mm) | 72.00 |
| Overall Length (mm) | 266.0000 |
| Overall Height (mm) | 156.00000 |
| Static Load Capacity (Pounds) | 10116.00 |
| Dynamic Load Capacity (Pounds) | 13668 |
| Distance Between Mounting Hole Centers (Decimal Inch) | 8.2700 |
| Material | Cast Iron/Steel |
| Distance Between Base And Center (mm) | 79.3750 |
| Insert Material | 52100 Steel |
| Lock Type | Set Screw |
| Bolt Size (Inch) | 3/4 |
| Metric Bolt Size | 20.0000 |
