#10 Screw, 0.204″ ID, Steel External Tooth Lock Washer 0.569″ OD, Zinc-Plated, Grade 1075
Item #: 93674885
Brand: Value Collection
Model #: LWDT-100USA
Product Specifications
| Tooth Type | External Tooth |
| Features | Dished |
| Material | Steel |
| Screw Size | #10 |
| Inside Diameter | 0.204 in |
| Outside Diameter | 0.569 in |
| System of Measurement | Inch |
| Thickness | 0.029 in |
| Finish | Zinc Plated |
| Inside Diameter (Decimal Inch) | 0.2040 |
| Outside Diameter (Decimal Inch) | 0.5690 |
| Maximum Inside Diameter | 0.204 in |
| Thickness (Decimal Inch) | 0.029 |
| Material Grade | 1075 |
| Military Specification | Does Not Meet Military Specifications |
| Standards | DIN 6798; DIN 6797 |
| Finish/Coating | Zinc-Plated |
| Minimum Inside Diameter (Decimal Inch) | 0.195 |
| Minimum Outside Diameter (Decimal Inch) | 0.556 |
| Maximum Outside Diameter (Decimal Inch) | 0.569 in |
