Seco - 3.52" Cut Diam, 0.177" Max Depth, 1" Arbor Hole, 6 Inserts, RN.N 32 Insert Style, Indexable Copy Face Mill - 9,100 Max RPM, 2.38" High
Item #: 93675700
Brand: Seco
Model #: 59852
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 3.5200 |
| Maximum Depth of Cut (Decimal Inch) | 0.1770 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Overall Height (Decimal Inch) | 2.3800 |
| Number of Cutter Inserts | 6 |
| Insert Compatibility | RN.N 32 |
| Through Coolant | No |
| Maximum RPM | 9100 |
| Insert Holding Method | Screw |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
| Keyway Width (Decimal Inch) | 0.3800 |
| Cutting Direction | Right Hand |
| Complete Insert Compatibility | RNGN 32E; RNGN 32S; RNGN 32S-00625; RNGN 32S-00625-LF; RNGN 32S-LF; RNMN 32E; RNMN 32S |
