Techniks - BT50 Taper Shank Rigid Tapping Adapter - #0 to 9/16" Tap Capacity, 3.07" Projection, Quick Change
Item #: 93904860
Brand: Techniks
Model #: 21480/50BT
Exact Tooling IR#: 04
Features and Benefits
Rigid or solid tapping styles are used for general purpose CNC machining. The rigid tapping cycle synchronizes the machine and spindle rotation to match a specific thread pitch. It is used at higher speeds, but does not compensate for length during the taping cycle.
Taper shanks maintain balance and rigidity during high speeds and heavy-duty applications. They have smaller diameters than straight shanks.
| Product Specifications | |
|---|---|
| Tapping Style | Rigid |
| Shank Type | Taper Shank |
| Taper Size | BT50 |
| Minimum Tap Capacity (Inch) | #0 |
| Maximum Tap Capacity (Inch) | 9/16 |
| Projection (Decimal Inch) | 3.0700 |
| Quick Change | Yes |
| Minimum Collet Capacity (mm) | M1.6-M3.5 |
| Minimum Collet Capacity (Inch) | #0; #6 |
| Maximum Collet Capacity (Inch) | 9/16 |
| Maximum Collet Capacity (mm) | M14 |
| Overall Length (Decimal Inch) | 7.0780 |
