Chicago-Latrobe - 1.5mm 135° High Speed Steel Jobber Drill - Exact Tooling

Chicago-Latrobe - 1.5mm 135° High Speed Steel Jobber Drill


Item #: 50956176
Brand: Chicago-Latrobe
Model #: 45805

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide prevents chip building, galling and welding on the workpiece. It is commonly used on low carbons, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (mm) 1.50
Drill Bit Size (Decimal Inch) 0.0591
Drill Point Angle 135
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Oxide
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (mm) 18.00
Flute Length (Decimal Inch) 0.7087
Overall Length (mm) 40.00
Overall Length (Decimal Inch) 1.5748
Point Type Split Point
Shank Diameter (mm) 1.50
Shank Diameter (Decimal Inch) 0.0591
Spiral Type Regular Spiral
Shank Length (mm) 22.00
Shank Length (Decimal Inch) 0.8661
Specification Designation NAS
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0005
Specification Number NAS 907-B
Drill Bit Grade Heavy Duty
Series/List 150ASP
$ 1.86
