Cle-Line - #8 135° High Speed Steel Jobber Drill - Exact Tooling

Cle-Line - #8 135° High Speed Steel Jobber Drill


Item #: 57607475
Brand: Cle-Line
Model #: C23206

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide prevents chip building, galling and welding on the workpiece. It is commonly used on low carbons, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (Wire) #8
Drill Bit Size (Decimal Inch) 0.1990
Drill Point Angle 135
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Oxide
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 2-7/16
Flute Length (mm) 61.91
Flute Length (Decimal Inch) 2.4375
Overall Length (mm) 92.08
Overall Length (Decimal Inch) 3.6250
Overall Length (Inch) 3-5/8
Point Type Split Point
Shank Diameter (mm) 5.05
Shank Diameter (Decimal Inch) 0.1990
Spiral Type Regular Spiral
Shank Length (mm) 30.16
Shank Length (Decimal Inch) 1.1874
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0007
Web Thinning Web-Thinned
Drill Bit Grade Heavy Duty
Series/List 1801
