Fixed Lifting Eye Bolt: Without Shoulder, 13,300 lb Capacity, 1 ™ Thread, Steel Partially Threaded, 12″ Shank, 4″ Thread Length
Item #: 96315783
Brand: US Cargo Control
Model #: GVEB1X12
Product Specifications
| Eye Bolt Type | Fixed |
| Shoulder Type | Without Shoulder |
| Lifting Capacity (Lb.) | 13300.00 |
| Eye Inside Diameter (Decimal Inch) | 2.0000 |
| Eye Inside Diameter (Inch) | 2 |
| Eye Outside Diameter (Decimal Inch) | 4.0000 |
| Eye Outside Diameter (Inch) | 4 |
| Thread Size | 1 in |
| Thread Length (Inch) | 4 |
| Full or Partial Threading | Partially Threaded |
| Thread Length (Mm) ( - 3 Decimals) | 4.00 |
| Thread Length (Decimal Inch) | 4.0000 |
| Overall Length (mm) | 16.31 |
| Overall Length (Decimal Inch) | 16.3100 |
| Shank Length (Inch) | 12 |
| Shank Diameter (Inch) | 1 |
| Material | Steel |
