Chicago-Latrobe - #10 135° High Speed Steel Jobber Drill - Exact Tooling

Chicago-Latrobe - #10 135° High Speed Steel Jobber Drill


Item #: 80905102
Brand: Chicago-Latrobe
Model #: 69010

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Parabolic flutes are constructed with a wider flute shape for increased chip flow.
Product Specifications
Drill Bit Size (Wire) #10
Drill Bit Size (Decimal Inch) 0.1935
Drill Point Angle 135
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Bright
Flute Type Parabolic
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 2-7/16
Overall Length (Inch) 3-5/8
Point Type Split Point
Shank Diameter (Decimal Inch) 0.1935
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) -0.0007 to 0.0000
Web Thinning Web-Thinned
Drill Bit Grade Heavy-Duty
Series/List 150DH
$ 4.40

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
