Komet - 10.7mm 140° Solid Carbide Jobber Drill - Exact Tooling

Komet - 10.7mm 140° Solid Carbide Jobber Drill


Item #: 66197310
Brand: Komet
Model #: V0310700112730

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium Aluminum Nitride (TiAlN) has a higher hardness and oxidation temperature versus TiN and TiCN. As a result, it is particularly advantageous for higher speed operations in a variety of steel machining applications.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (mm) 10.70
Drill Bit Size (Decimal Inch) 0.4213
Drill Point Angle 140
Drill Bit Material Solid Carbide
Drill Bit Finish/Coating TiAlN
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through Coolant Through
Overall Length (mm) 118.00
Overall Length (Decimal Inch) 4.6457
Flute Length x Diameter Ratio 5xD
Shank Diameter (mm) 12.00
Shank Diameter (Decimal Inch) 0.4724
Maximum Drilling Depth (Decimal Inch) 2.2047
Maximum Drilling Depth (mm) 56.00
Spiral Type Regular Spiral
Shank Length (mm) 45.00
Shank Length (Decimal Inch) 1.7717
Specification Designation DIN
Web Configuration Tapered
Web Thinning Web-Thinned
Specification Number DIN 6535HA
Drill Bit Grade High Performance
Series/List KUB Drillmax
$ 228.35

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
