Brand: Widia / Part #: 6664874
Item #: 33971102
Brand: Widia
Model #: 6664874
Product Specifications
| Mill Diameter (Inch) | 1 |
| Coating/Finish | AlTiN |
| End Mill Material | Solid Carbide |
| Number Of Flutes | 6 |
| Overall Length (Inch) | 5 |
| Length of Cut (Inch) | 2-1/4 |
| Cutting Direction | Right Hand |
| Mill Diameter (Decimal Inch) | 1.0000 |
| Flute Direction | Right Hand |
| Overall Length (Decimal Inch) | 5.0000 |
| Chipbreaker | Yes |
| Length Of Cut (Decimal Inch - 4 Decimals) | 2.2500 |
| Length Type | Regular |
| Flute Type | Helical |
| Extended Reach | No |
| Shank Type | Weldon Flat |
| Centercutting | Yes |
| Material Removal Type | Roughing |
| Minimum Helix Angle | 45.00 |
| Maximum Helix Angle | 45.00 |
| Primary Workpiece Material | Stainless Steel |
| Primary Workpiece Material Code | M |
| Secondary Workpiece Material | Cast Iron; High Temperature Alloy |
| Secondary Workpiece Material Code | S; K |
| Material Grade | AlTiN-MW |
| Series | 4U80 |
