Schunk - Soft Lathe Chuck Jaws Jaw Type: Square Material: Steel
Item #: 62543111
Brand: Schunk
Model #: 132618
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
Product Specifications
Soft Lathe Chuck Jaws; Jaw Type: Square ; Material: Steel ; Jaw Interface Type: 1.5mm x 60 Serrated ; Maximum Compatible Chuck Diameter (Inch): 12 ; Maximum Compatible Chuck Diameter (mm): 315.00 ; Minimum Compatible Chuck Diameter (mm): 315.00
| Jaw Type | Square |
| Material | Steel |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Maximum Compatible Chuck Diameter (Inch) | 12 |
| Maximum Compatible Chuck Diameter (mm) | 315.00 |
| Minimum Compatible Chuck Diameter (mm) | 315.00 |
| Minimum Compatible Chuck Diameter (Inch) | 12 |
| Overall Height (mm) | 100.00 |
| Groove Width (mm) | 21.00 |
| Distance Between Mount Hole Centers (mm) | 30.00 |
| Jaw End Shape | Pointed |
